Ascend Cruiser Manuel Du Propriétaire page 39

ADJUSTING THE SEAT HEIGHT
WARNING!
Improperly adjusted seat height could affect the rider's ability
to reach the handlebar and pedals may result in an unexpected
movement, loss of control and serious injury or death. Follow
these guidelines when adjusting the seat height. Always
ensure the seat post minimum insertion marks are below the
seat clamp and cannot be seen. Ensure the seat clamp is
locked and the seat cannot move.
Bolted Seat Clamp
❶ Using a 5 mm Allen wrench, loosen the seat clamp bolt.
Figure 4.18
❷ Adjust the seat height up or down until the rider feels they
have control of the bicycle and are comfortable.
Important! Be sure the minimum insertion marks do not go
past the top of the seat clamp and are not visible. See
Section 1, Fig. 1.2: Seat Height and Handlebar Reach.
❸ Tighten the seat clamp bolt to lock the seat in place.
❹ Check the seat to be sure it does not move.
2
1
Use a 5 mm Allen
wrench to loosen and
tighten the seat clamp
Adjustments 4
Minimum
insertion
marks
Seat tube
Figure 4.18
37
