MAINTENANCE

Malfunction
When the column is powered, the
buzzer makes a long beep (5s).
(Reset made with the "reset"
jumper)
The cells are interrupted but the
red light "Alarm" is off on the RX
column.
Press a long time on the "Select"
button (>2s) to be in the
alignment mode, no effect.
In alignment mode, there is no
signal.
No beep of the buzzer when
starting
Red light "Alarm" flashing on the
RX column.
Probable cause
 Low battery tension.
 There are less than 3 cells
connected on the column.
 The 2 cells are not cut at the
same time.
 Low battery tension.
 Tamper closed
 Fuse of control board out of
order
 Jumper pin ON/OFF away
 Low battery tension.
 Wrong optical alignment.
 Power of the beam too low.
 The cells in alignment mode on
the transmitter and receiver
columns do not have the same
number.
 Different channel on the
columns forming the detection
zone.
 Infrared disruption.
 Jumper pin ON/OFF away
 Fuse of the control board out of
order
 Battery out of order
 At least 1 cell is blocked.
 Wrong optical alignment
- 52 -
Solution
 Battery tension < 3.85V
(The panel is disconnected or
covered, replace the battery
pack).
 Check the cells connection.
 Block 2 cells at the same time.
 Battery tension < 3.85V
(The panel is disconnected or
covered, replace the battery
pack).
 Check the tamper contact.
 Check the fuse
 Verify jumper pin ON/OFF
 Battery tension < 3.85V
(The panel is disconnected or
covered, replace the battery
pack).
 Do the optical alignment
again. (§5.1)
 Increase the power of the
beam with the potentiometer
(§5.5).
 Put the cells under the same
number in alignment mode.
(§5.5)
 Put the same channel on both
columns. (§5.3)
 Check that the channels of the
other barriers are different.
(§5.3)
 Check the jumper pin ON/OFF
 Check the fuse
 Very low battery tension
 Check that the cells are clear.
 Check that ice and fog shields
do not disturb the cells. (§6)
 Eject the infrared beam by
disconnecting the RX and TX
cells and reset.
 Do the optical alignment again
(§5.1)
