Introduction; Main Features - SORHEA SOLARIS Notice D'installation

SORHEA
1

INTRODUCTION

The active infrared barriers SOLARIS are entirely autonomous and do not need any wiring.
The alarm information is transmitted through the radio coordination unit to the MAXIBUS III Hub.
Power is supplied thanks to an integrated solar panel and battery pack that guarantee the column's
autonomy in all weathers.
The active infrared barriers SOLARIS generate alarm information when 2 parallel cells are cut. They
consist of a transmitter column (TX) and a receiver column (RX) to be installed face to face and at the
distance that is to be protected. The barrier creates a virtual wall of detection that is invisible and
impenetrable.

MAIN FEATURES:

 Maximum outdoor range:
 Barriers with 3 to 10 double beam cells per direction (with automatic detection of the cells)
in heights of 1.5 m / 5 ft, 2 m / 7 ft, 2.5 m / 8.2 ft and 3 m / 10 ft.
 Simple face (SF) and double face (DF) columns allowing an optimal control of the
positioning of the cells.
 4 infrared selectable channels allowing to differentiate the barriers among themselves.
 Integrated alignment tools on each TX and RX column: optical sights, LEDs and a buzzer
that indicates the reception quality of the incoming signal.
 Integrated anti climbing cap.
 Options:
 Additional solar panel
 Concrete block
 Floor socket
 Wall fastening Kit
75 m / 246 ft
- 29 -
SOLARIS
