English
Discard the battery pack with due care for
the environment.
Charge D
WALT battery packs only with designated
e
D
WALT chargers. Charging battery packs other
e
than the designated D
D
WALT charger may make them burst or lead to
e
other dangerous situations.
Do not incinerate the battery pack.
Battery Type
The DCD700 operates on a 10.8/12V battery pack.
These battery packs may be used: DCB122, DCB124, DCB125
and DCB127. Refer to Technical Data for more information.
Package Contents
The package contains:
1 Drill/driver
1 Charger
2 Batteries
1 Bag
1 Instruction manual
•
Check for damage to the tool, parts or accessories which may
have occurred during transport.
•
Take the time to thoroughly read and understand this manual
prior to operation.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Date Code Position
The date code, which also includes the year of manufacture, is
printed into the housing.
Example:
2019 XX XX
Year of Manufacture
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury could result.
Variable speed trigger
1
switch
Forward/reverse button
2
Torque adjustment collar
3
Gear shifter
4
Intended Use
This drill/driver is designed for light fastening and drilling
applications.
DO nOT use under wet conditions or in the presence of
flammable liquids or gases.
8
WALT batteries with a
e
Keyless chuck
5
Battery release button
6
Battery pack
7
Worklight
8
This drill/driver is a professional power tool.
DO nOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
this tool.
•
This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
WARNING: Use only D
e
Inserting and Removing the Battery Pack
from the Tool (Fig. C)
nOTE: Make sure your battery pack
To Install the Battery Pack into the Tool
Handle
1. Align the battery pack
7
with the rails inside the tool's
handle (Fig. C).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap into place.
To Remove the Battery Pack from the Tool
1. Press the release button
6
out of the tool handle.
2. Insert battery pack into the charger as described in the
charger section of this manual.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicable regulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
Proper Hand Position (Fig. H)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
sudden reaction.
Proper hand position requires one hand on the main handle
WALT battery packs and chargers.
7
is fully charged.
and firmly pull the battery pack
9
.
