5 Versions

5.1 Built-in Wiper

The pan & tilt can be fitted with a wiper.
Fig. 02
To operate the wiper, refer to "11.7 Enabling the Wiper
(Wiper)", page 45.

5.1.1 Washer

If the pan & tilt is fitted with a wiper, it can also have
an external pump supplying water to clean the glass.
As shown in the picture, the spray to clean the glass is
outside the pan & tilt.
Fig. 03
Once the command has been sent ("11.8 Enabling the
Washer (Washer)", page 45) the pan & tilt positions
itself with the glass facing the spray and the pump
and wiper are activated for a set period of time; at the
end of the operation the pan & tilt returns to its initial
position.
For models with Washer complete with level sensor,
the pan & tilt can also display a video message when
the level of the liquid inside the tank is too low (only
if using a high prevalence pump of the UPTWAS
series).
j For further details on configuring and using
the Washer, refer to "9.6.8.2 Washer Menu",
page 36.
10

5.2 IP video encoder

The pan & tilt can be fitted with a board for video
output through ethernet ("9.7 IP Board Configuration",
page 37).
Fig. 04
