The User Interface (UI)

All system programming and setup is performed through the
AquaLink Z4 UI located on the front of the controller.
NOTE: The installer may relocate the UI. It is critical that the UI be
mounted outdoors, where a service professional may access it
at any time.
Menu Screen
Back Button
Power Light
Z4 | Owner's Manual Z4 | Owner's Manual
Using the Z4 Controller
Zodiac
12:40PM
Pool Mode
Pool Heater
Spa Mode
Spa Heater
Settings
Devices
Back
Power
ENGLISH
More
O
74°F
O
O
>
>
Up/Down (Scroll)
Arrows
Select
Alert
Power Button
®
Page 7
Select Button
Alert Light
