5

LUBRICATION

5.1

LUBRICATION CHART______________________________________________________

6
15
Grease Fitting Locations
F1 - 50 Hours (Every Week)
1
2
3
4
5
6
7
8
9
10
11
12
1
2
4
3
4
5
12
11
8
10
Caster Spindles
Caster Wheel Axles
Gauge Wheel Axles
Lift Cylinder - Front Deck
Lift Arm - Front Deck
Side Deck Pivots
Steering Cylinder
Tie Rod
Axle Pivot
Wheel Pivot
Lift Arm - Side Deck
Lift Cylinder - Side Deck
12
1
14
13
8
9 7
10
Qty F2 - 150 Hours
(10) 13 Drive Shaft U-Joint
(10) 14 Drive Shaft Slip Joint
(2) 15 Return Canister Pivot
(4)
(2)
(6)
(2)
(2)
(1)
(2)
(2)
(4)
LUBRICATION
4
3
4
5
7
Qty
(2)
(1)
(6)
5
1
2
HR014
GB-21
