REPAIR PARTS LIST FOR USER CONTROL ASSEMBLY
Ref.
No. Description
1 Control panel with rivet nuts
2 Control panel top painted
3 GFCI Circuit breaker cover
4 GFCI Circuit breaker - 30A
5 Cover plate - GFCI
6 Twist lock cover
7 Twistlock receptacle: 120V - 250V / 30A
8 Pan head screw, #8 - 32 x 1/2
9 Duplex receptacle cover
10 Duplex receptacle: 120V, 20A
11 Pan head screw, #6 - 32 x 3/8 inch
12 Thermal circuit protector, 20A
13 Toggle switch DPDT ON/ON
14 Toggle switch ON/OFF
15 Fuse holder housing
16 Fuse, 15A slow blow (not shown)
17 Rivet nut, 1/4 - 20 UNC, 0.580 L
18 Pan head screw, #8 - 32 x 3/4 inch
19 Circuit board post, #6 - 32, female
20 Pan head screw, #6 - 32 x 1/4 inch
21 Idle control board
22 Pan head screw,1/4 - 20 x 3/4 inch
23 Hex washer head bolt, 1/4 - 20 x 3/4 inch
24 Hex nylok nut, #8 - 32 (not shown)
Honda Charging System Rectifier - 3 Amp
25
[Honda P/N: 31700-124-008] (Not Shown)
26 Rectifier, idle control
27 #8 Internal / external tooth lock washer
28 Toggle Switch SPST OFF - (ON) (momentary)
29 Transformer (SDR8CGW1 only, not shown)
Complete control panel assembly [wired] with 1/4 inch tube, FEP
30
(MJ115022AV)
-- Not available
✝
Available at local hardware store
Part Number:
GW010437SJ
GW010427KK
GN051022AV
GN051042AV
GN051024KK
GN051020AV
GW004292AV
✝
GN051021AV
GN003403AV
✝
GN051041AV
GW004258AV
PM351124AV
HV010201AV
✝
MJ105205AV
✝
✝
✝
GW005068AV
✝
✝
✝
Contact Honda for this part
GN006651AV
MJ105715AV
GW004259AV
GW005056SJ
GW010438SJ
Qty.
1
1
1
1
1
1
1
2
2
2
8
2
1
1
1
1
5
2
4
4
1
7
7
4
1
1
1
1
1
2
1
33
