BEFORE YOU BEGIN
Introduction
The Speedaire combination units are the solution for offsite, remote jobs. These units are mobile power sources
that can be used as a generator, welder or air compressor.Powered by an air-cooled four cycle engine, this
machine is designed to run at maximum RPM when there is demand for air or electric power. When there is no
demand for power the unit idles down to save fuel.
Speedaire Combination Units Include:
• Compressor pump
• Generator
• Welder
• ASME air receiver with safety valve
• Unloader valve
• Thermostatically protected alternator
Quick Reference
Recommended Oil (2 Options)
Single viscosity SAE 30 ISO100 nondetergent compressor oil. Grainger part number
1WG49.
10W30 synthetic oil such as Mobil 1
Oil Capacity
Approximately 2 quarts
UNPACKING
tubes or coolers. Do not use unit to lift other attached equipment.
After unpacking the unit, inspect carefully for any damage that may have occurred during transit. Check for
loose, missing or damaged parts. Check to be sure all supplied accessories are enclosed with the unit. In case of
questions, damaged or missing parts, please call 1-888-606-5587 for customer assistance.
Required Items - Not Included
• Oil
• Welding Cables
• Welding Sticks
® .
Do not lift or move unit without appropriately rated equipment. Be sure
the unit is securely attached to lifting device used. Do not lift unit by holding onto
Do not operate unit if damaged during shipping, handling or use. Damage
may result in bursting and cause injury or property damage.
1
