2 In the rooms view, activate the
edit mode.
3 Select the chosen room and press
the "Add device" button.
4 Press the button three times in rapid
succession to put the sensor into
inclusion mode.
5 The app displays a confirmation
message once inclusion has been
successfully completed.
Removing MotionSwitch LED from
the Smart Friends system:
1 In the rooms view, activate the
edit mode.
2 Select the device in the chosen room
and press the "delete" button.
Press "delete" and follow the
instructions in the app.
3 To put the sensor into exclusion
mode, press the button three times
in rapid succession.
4 The app displays a confirmation
message once exclusion has been
successfully completed.
Setting the MotionSwitch LED via
the app
– After programming, an ON/OFF
scene is automatically created in
the app.
– The following setting values are then
automatically stored:
a ) Twilight setting
b ) Time setting = 3-minute switch-
off delay
– The twilight and time settings can
be selected to the accuracy of one
lux / second in the "Scene" menu.
Returning the MotionSwitch LED to
factory settings:
Please only perform these steps if the
main network controller is missing or
not working for other reasons.
1 To set the sensor to "Reset", press
the button three times in rapid
succession and then press it once
for several seconds.
2 The device is now no longer included
in the Z-Wave system and has been
returned to factory settings.
Note:
The latest firmware version for the light
is available for downloading from
z-wave�steinel�de.
7� EC Declaration of
Conformity
STEINEL Vertrieb GmbH hereby
declares that the MotionSwitch
LED Z-Wave radio equipment type
conforms to Directive 2014/53/EU.
The full wording of the EU Declaration
of Conformity is available for download-
ing from the following Internet address:
http://www�steinel�de
8� Maintenance / care
The product requires no maintenance.
The MotionSwitch LED can be cleaned
with a damp cloth (without detergents)
if dirty.
9� Disposal
Electrical and electronic equipment,
accessories and packaging must be
recycled in an environmentally compat-
ible manner.
Do not dispose of electrical
and electronic equipment as
domestic waste.
- 12 -
EU countries only:
Under the current European Directive
on Waste Electrical and Electronic
Equipment and its implementation in
national law, electrical and electronic
equipment no longer suitable for use
must be collected separately and recy-
cled in an environmentally compatible
manner.
10� Manufacturer's Warranty
This Steinel product has been
manufactured with utmost care, tested
for proper operation and safety and
then subjected to random sample
inspection. Steinel guarantees that
G B
it is in perfect condition and proper
working order. The warranty period is
1
36 months and starts on the date of
Y E A R
sale to the consumer. We will remedy
defects caused by material flaws or
MANUFACTURER'S
WARRANTY
manufacturing faults. The warranty will
be met by repair or replacement of
11� Technical specifications
Dimensions H x W x D
Mains power supply
Sensor technology
Angle of coverage
Detection zone
Time setting
Twilight setting
Temperature range
Z-Wave wireless range
Radio frequency band
Transmitter power
defective parts at our own discretion.
The warranty shall not cover damage to
wear parts, damage or defects caused
by improper treatment or maintenance.
Further consequential damage to other
objects shall be excluded.
Claims under the warranty will only
be accepted if the unit is sent fully
assembled and well-packed with a brief
description of the fault, a receipt or
invoice ( date of purchase and dealer's
stamp ) to the appropriate Service
Centre.
Repair service:
If defects occur outside the warranty
period or are not covered by the war-
ranty, ask your nearest service station
for the possibility of repair.
5
3
Y E A R Y E A R
MANUFACTURER'S MANUFACTURER'S
WARRANTY WARRANTY
55 × 55 × 56 mm
230-240 V, 50 Hz
Passive infrared
180°
20 m
3 min factory setting /
5 s to 15 min via the app
2-2000 lux via the app
10°C to 35°C
approx. 100 m
(unobstructed line of vision)
868 MHz
≤ 2.5 mW
