10 Disposal of waste
materials
This symbol mark and recycle system
are applied only to EU countries and not
applied to the countries in the other area of
the world.
Your product is designed and manufactured with
high quality materials and components which can be
recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed of
separately from your household waste.
Please dispose of this equipment at your local
Community waste collection or Recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.

11 Technical data

11.1 General

Constructed from aluminium
Sunshield in ABS
Epoxypolyester powder painting, RAL9002 colour
Stainless steel external screws

11.2 Mechanical

Cable glands: 1xM12, 1xM16, 1xM20
Glass window (WxH): 118x75mm (4.6x2.7in)
Internal usable area (WxHxL): 100x70x250mm
(3.9x2.7x9.8in)
Unit weight: 3.1kg (6.6lb)

11.3 Electrical

Power absorbed in input: PoE class 3 (13W) or Hi-PoE
class 4 (25W) selectable from dip switch
Available power for camera (PoE IN class 3): PoE classe
2 (7W)
Available power for camera (Hi-PoE IN class 4): PoE
class 3 (13W) with Ton -10°C ±2°C "cold start" function
Data line: 10/100Base-T
Illuminator GEKO IRH, low power: 6W
Heating: 8W, electronically controlled, Ton 20°C±2°C
(68°F±4°F), Toff 23°C±2°C (73.4°F±4°F)
Fan with thermostat for camera cooling for versions
with double air filter: Ton 35°C±2°C (95°F±4°F), Toff
32°C±2°C (89.6°F±4°F)
Demisting with forced hot air: 5W
Anti-icing heated glass: 5W, Ton 30°C±2°C (86°F±4°F),
Toff 33°C±2°C (91.4°F±4°F)
Compatible with IEEE 802.3af, IEEE 802.3at/PoE Plus
Compatible with the Power Injector (OHEPOWINJ:
VIDEOTEC optional accessory)

11.4 Environment

Indoor/Outdoor
Maximum temperature range : -30°C/+60°C (140°F)
(refer to the table: Available models and features)
The correct functioning of the device, within the recommended
temperature range, is ensured using camera and lens with a
temperature range from -10°C (14°F) to +60°C (140°F)
Resistant to salty fog until 1000 hours (according to
ISO9227)

11.5 Certifications

CE EN61000-6-4, EN60950-1, EN50130-4
IP66/IP67, EN60529 (with cable glands)
IP66/IP67, EN60529 (with special gaskets and bracket
with internal cable channel)
IP55, EN60529 (with bracket with internal cable
channel)
IP44, EN60529 (for models with double filter for
ventilation)
