OPERATING STATUS
LED LED Status
LD1 (Power) Off
On
LD2 (Ca- Off
mera)
On
1 flashing
2 flashings
5 flashings
9 flashings
LD3 (De- Off
mist)
1 flashing
2 flashings
On
LD4 (He- Off
ater)
1 flashing
On
LD5 (IR) Off
1 flashing
LD6 (Cold Off
Start)
1 flashing
On
Tab. 4
10
Apparatus Status
The device is not powered
The device is correctly powered
The camera is not connected or
Cold Start is active
The camera is correctly powered
The camera has a low identifica-
tion resistance
The camera has a high identifica-
tion resistance
The camera has an excessive
energy consumption
The camera requires more energy
than the available
Demisting was not correctly
detected
Standard demisting is inactive
The anti-ice system (optional) is
inactive
Demisting, or anti-ice system, is
in function
Heating is not available or power
available is not sufficient
Heating is inactive
Heating is active
The illuminator (optional) is not
detected or the available power is
not sufficient
The illuminator is correctly
powered (illuminator activation is
controlled by its photocell)
Heating is not available
The pre-heating procedure is
inactive
The pre-heating procedure is
underway

9 Maintaining and cleaning

9.1 Maintaining

9.1.1 Kit for upgrading of the systems

The kit cannot be installed in the housing
versions equipped with wiper.
Remove the slide (01), the electronic board (02) and
the heating (03).
02
Fig. 16
For kit installation information refer to chapter 6
Assembling and installing, page 5.

9.2 Cleaning

9.2.1 Window and plastic cover cleaning
(PC)
Avoid ethyl alcohol, solvents, hydrogenated
hydrocarbide, strong acid and alkali. Such
products may irreparably damage the
surface.
Surface dirt should be rinsed away with water and
then the window cleaned with a neutral soap diluted
with water, or specific products for spectacle lens
cleaning. These should be applied with a soft cloth.
01
03
