Operating Conditions - Axis Q60 Série Guide D'installation

Function Pin – wire
Configurable 2 – blue
(Input or
Output)
7 – yellow
RX+
3 – green/white
4 – green
RX-
TX+
5 – orange/white
6 – orange
TX-
GND 8 – black
12 V power 1, 9 – red
Specifications

Operating Conditions

The Axis product is intended for outdoor use.
Classification
AXIS Q6042-C/Q6044-C/Q6045-C
1. Protected against entry of sand and dust. Clear/smoked dome cover may need to be replaced if exposed to
sandblasts.
Notes
Digital input – Connect to GND
to activate, or leave floating
(unconnected) to deactivate.
Digital output – Internal connection
to ground when activated, floating
(unconnected) when deactivated.
If used with an external relay, a
diode must be connected in parallel
with the load, for protection against
voltage transients.
Ethernet – receiving
Ethernet – receiving
Ethernet – transmitting
Ethernet – transmitting
Ground
Used to power camera
IEC 60721-3-4 Class 4K4H, 4M4
IEC 60529 IP66
NEMA 250 Type 4x
MIL-STD 810G 500.5, 501.5, 502.5, 503.5, 505.5, 506.5,
1
507.5, 509.5, 510.5
18
AXIS Q60 Series
Specifications
0 to +30 V DC
Max load =
100 mA
Max voltage =
+30 V DC
12–13.2 V DC
Max load = 6 A
, 514.6
