4.3 Noise and vibration information
Sound pressure level
Idling / processing
Noise power level
Idling / processing
Measurement tolerance
Wear ear protection!
Measured acceleration
The specifi ed emissions values (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary es-
timates regarding vibration and noise loads
during operation.
– They represent the primary applications of the
power tool.
Increase possible for other applications, with oth-
er insertion tools or if not maintained adequately.
Take note of idling and downtimes of machine!
4.4 Residual risks
In spite of compliance with all relevant design
regulations, dangers may still present them-
selves when the machine is operated, e.g.:
- Workpiece parts being thrown off,
- Parts of damaged tools being thrown off,
- Noise emission,
- Sawdust emission.
5

Setting up, commissioning

Ensure that the fl oor around the machine is level,
in good condition and free of loose objects (e.g.
chips and offcuts).
5.1 Mounting the machine
The machine can be set up with or without the
legs folded out (Fig. 1 and 2) (the „Floor" model
does not include folding legs).
To fold out the legs, open the four rotary knobs
[1-6] as far as they will go. After folding out the
legs, retighten the four rotary knobs.
So that the machine stands securely, the length
of one of the legs can be changed by turning the
cap on the end [1-7].
5.2 Prior to initial operation
Fitting the guard
- Remove the yellow safety sticker.
- Set the saw to the maximum cutting height, see
sec. 7.1.
- In this position, screw the supplied upper guard
[6-4] with the rotary knob [6-5] to the spacer
wedge [6-6].
5.3
84 / 90 dB(A)
97 / 103 dB(A)
K = 3 dB - Engage the saw unit in the zero position.
- Remove all attachments from your saw and wind
up the cable on the cable holder.
- Fold up the legs.
< 2.5 m/s²
5.4
The machine can be used as a bench-mounted
circular saw or as a circular trimming saw.
a)
- Set the switch [1-9] to the lower position.
- Swing the hand grip [1-8] downwards, and use
the hand grip to pull the saw unit forwards until
it locks into place.
The saw unit is now in a central bench position
and the machine can be used as a bench-mounted
circular saw.
b)
- Set the switch [3-10] to the upper position.
If the hand grip [3-9] is swung downwards, it can
be used to move the saw unit backwards and for-
wards for drawing cuts. The backward movement
is supported by spring force.
5.5
The extraction set CS 70 AB (488292, included in
scope of delivery for CS 50 EB) joins both of the
extraction connections so that a Festool extractor
module can be connected.
5.6
On account of the performance capability of the
motor, we recommend a 16 A fuse.
To switch on, press the ON/OFF switch [4-1] and
the locking switch [4-4] simultaneously. The
machine runs as long as the ON/OFF switch is
pressed.
For continuous operation after switching on, fi rst
press the ON/OFF switch [4-1] and then let go of
18
Transport
When transporting the power tool, hold it
only by the sides [1-11]. Never take hold
of, or transport the power tool, by the
protective cover.
Applications
Bench-mounted circular saw (Fig. 1)
Circular trimming saw (Fig. 3)
Dust extraction
The PRECISIO has two extraction con-
nections: the upper protective cover [2-3]
with a diameter of 27 mm, and the lower
protective cover [2-2] with a diameter of
35 mm.
Power supply and start-up
The mains voltage must correspond to
the specifi cation on the rating plate.
In North America, only Festool machines
with the voltage specifi cations 120 V/60
Hz may be used.
