7.2.10.2 Synchronisation with an external
twilight switch
To synchronise the illuminators and camera with an
external light sensitive switch you need to:
• Connect the twilight switch to the terminals: AL1/A
GND (7.2.3.4 Connection of the alarm inputs, of the
twilight switch and of the relays, page 23).
• Adjustment of the illuminator on the left (MASTER):
• Lighting threshold: Set the value to OFF (
7.2.10.5 LED illuminator switching on threshold
adjustment, page 29).
• Infrared power: Set the value as needed
(7.2.10.6 LED illuminator power adjustment,
page 29).
• Adjustment of the the illuminator on the right
(SLAVE):
• Lighting threshold: Set the value to the
maximum (7.2.10.5 LED illuminator switching on
threshold adjustment, page 29).
• Infrared power: Set the value to the minimum
(7.2.10.6 LED illuminator power adjustment,
page 29).
From the IR Probe entry select the External option (
9.1.13 Camera Parameters, page 40).
On the I/O digital board set the values in the
following manner:
• Alarm ID: 1
• Type: NORMALLY OPEN
• Action: IR_FILT
7.2.10.3 Synchronising the unit with the
infrared illuminators
To synchronise the unit with the infrared illuminators
it is necessary to:
• Adjustment of the illuminator on the left (MASTER):
• Lighting threshold: Set the value as needed (
7.2.10.5 LED illuminator switching on threshold
adjustment, page 29).
• Infrared power: Set the value as needed
(7.2.10.6 LED illuminator power adjustment,
page 29).
28
• Adjustment of the the illuminator on the right
(SLAVE):
• Lighting threshold: Set the value to the
maximum (7.2.10.5 LED illuminator switching on
threshold adjustment, page 29).
• Infrared power: Set the value to the minimum
(7.2.10.6 LED illuminator power adjustment,
page 29).
From the Camera Parameters entry select the Internal
option (9.1.13 Camera Parameters, page 40).
7.2.10.4 Manually activate the LED
illuminator
To turn on the LED illuminators:
• Adjustment of the illuminator on the left (MASTER):
• Lighting threshold: Set the value to OFF (
7.2.10.5 LED illuminator switching on threshold
adjustment, page 29).
• Infrared power: Set the value as needed
(7.2.10.6 LED illuminator power adjustment,
page 29).
• Adjustment of the the illuminator on the right
(SLAVE):
• Lighting threshold: Set the value to the
maximum (7.2.10.5 LED illuminator switching on
threshold adjustment, page 29).
• Infrared power: Set the value to the minimum
(7.2.10.6 LED illuminator power adjustment,
page 29).
