Ryobi RBC430SESC Manuel D'utilisation page 23

Figure 14
40. Blade protector
Figure 15
49. Cover
50. Latches
51. Bump/Feed knob
52. Hex bolt
53. Spool
54. Spring
55. Line trimmer head
56. Latch opening
Figure 16
45. Oil cap/dipstick
46. Hatched area
47. Funnel
48. Oil fill hole
Figure 17
57. Top cover
58. Screw
59. Spark plug
RBC430SBSC
Figure 1
1. Shoulder strap
TM
2. Tri-arc Blade
3. Drive shaft
4. Coupler
5. Strap hanger
6. Ignition switch
7. Trigger lock
8. Left handle
9. Primer bulb
10. Fuel cap
11. Recoil starter
12. Throttle trigger
13. Latch
14. Right handle
15. Wing knob
16. Blade guard
17. Choke lever
18. Grass deflector
19. Cutting line
20. ReelEasy string head
TM
48a. Quick release tap
48b. Latch
Figure 2
3. Drive shaft
21. Lock Button
22. Guide recess
23. Power head (upper shaft)
English(Original instructions)
24. Position hole
24. Position hole
Figure 3
25. Hole on the attachment hanger to fit lock button of
26. Attachment hanger
27. Hole on lower attachment
Figure 4
28. Clamp
29. Bolt
30. Mounting bracket
Figure 5
16. Blade guard
18. Grass deflector
31. Gear case assembly
32. Holding pin tool
33. Mounting bracket
34. Wrench
35. Cupped washer
36. Nut
Figure 10
37. Trimmer line cut-off blade
Figure 12
38. Full choke position
38b. Half choke position
39. Run position
Figure 13
13. Latch
42. Filter
43. Air filter cover
Figure 14
40. Blade protector
Figure 15
49. Cover
50. Latches
51. Bump / Feed knob
52. Hex bolt
53. Spool
54. Spring
55. Line Trimmer head
56. Latch opening
Figure 16
44. Oil cap/dipstick
45. Hatched area
46. Funnel
47. Oil fill hole
Figure 17
21
lower booms
