SERVICE
Servicing requires extreme care and knowledge
and should be performed only by a qualified service
technician. For service we suggest you return the product
to your nearest AUTHORISED SERVICE CENTER for
repair. When servicing, use only identical replacement
parts.
WARNING:
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator's manual.
If you do not understand the warnings and
instructions in the operator's manual, do not
use this product. Call Ryobi customer service for
assistance.
WARNING:
The operation of any power tool can result in
foreign objects being thrown into your eyes,
which can result in severe eye damage. Before
beginning power tool operation, always wear
safety goggles or safety glasses with side
shields and, when needed, a full face shield. We
recommend Wide Vision Safety Mask for use
over eyeglasses or standard safety glasses with
side shields. Always use eye protection which is
marked to comply with EN 166.
SAVE THESE INSTRUCTIONS
INTRODUCTION
This product has many features for making its use
more pleasant and enjoyable. Safety, performance, and
dependability have been given top priority in the design
of this product making it easy to maintain and operate.
DESCRIPTION OF FIGURES
RBC430SESC
Figure 1
1. Shoulder strap
TM
2. Tri-arc Blade
3. Drive shaft
4. Coupler
5. Strap hanger
6. Ignition switch
7. Trigger lock
8. Rear handle
9. Primer bulb
10. Fuel cap
11. Recoil starter
English(Original instructions)
12. Throttle trigger
13. Latch
14. Knob
15. Front handle
16. Blade guard
17. Choke lever
18. Grass deflector
19. Cutting line
20. ReelEasy
42a. Quick release tap
42b. Latch
Figure 2
3. Drive shaft
21. Lock Button
22. Guide recess
23. Power head (upper shaft)
24. Position hole
Figure 3
25. Hole on the hanger cap to fit lock button of lower
26. Hanger cap
27. Hole on lower attachment
Figure 4
28. Clamp
29. Screw
30. Bracket
Figure 5
16. Blade guard
18. Grass deflector
20. ReelEasy
31. Gear case assembly
32. Holding pin tool
33. Mounting bracket
34. Wrench
35a. Cupped washer
35b. Blade retainer nut
36. Bolt
Figure 10
37. Trimmer line cut-off blade
Figure 12
38. Full choke position
38b. Half choke position
39. Run position
Figure 13
13. Latch
43. Filter
44. Air filter cover
