Panel Dimensions
Large Panel: GP48-GP72 (120/277 V
Dimensions are in inches (mm).
4 (102) dia.;
punch for
alt. load
wiring
86
(2184)
84.75
(2153)
54.5
(1384)
30.5
(775)
1.875
10.5
6.5
(267)
(165)
14.125
(359)
Left Side
2.19 (56)
1.875 (48)
3 (76)
R
52.31 (1329)
23 (584) 23 (584)
Top View: GP48 - GP72
50 (1270)
25.06
(637)
(48)
27.25 (692)
51.125 (1299)
Back View: GP48 - GP72
24.25
(616)
23.31
(592)
28 (711)
28.94 (735)
49.44 (1256)
50.44 (1281)
Bottom View: GP48 - GP72
only)
9/16 (14) dia.
mounting hole;
use 1/2 in.
(13 mm)
hardware
Installation Guide for Dimming Panels 7
