8. Connecting the communication accessories

The following communication accessories can be incorporated in the INGECON SUN ComBox, with the option of
different ways of communicating locally and/or remotely.
See section "10. Operation" for examples of the INGECON SUN ComBox with the different
communication accessories set out here.
All the communication accessories come connected as standard to the INGECON SUN ComBox base
plate by requesting the required communication method at the time of ordering the device.

8.1. GPRS Modem - AAX7014

1. Insert the GPRS modem in its designated slot in the INGECON SUN ComBox base plate.
2. The jumper that is wired as standard to the J11 connector of the base plate must be disconnected at one
end.
