d) Voltage measurement 'V'
AC voltage measurement (V )
• Switch the product on at the rotary switch (3) and
select the measurement range V
appear on the display.
• Insert the red test lead into the V socket (6) and the
black test lead into the COM socket (7).
• Connect both of the probe tips to the measured object
(generator, mains voltage, etc.).
• The measured value is shown on the LC display (5).
• Do not measure voltages above 750 V/AC. You will
hear a continuous beep if the measurement range is
exceeded (750 V/AC).
If the voltage exceeds 30 V/AC, the LC display
shows a visual high-voltage warning to warn of
the danger of an electric shock.
• After completing the measurement, remove the current
clamp from the measured object and switch the
product off.
. 'AC' and 'V'
