en
Pos. Name Explanation
Blue LED in- Pump is influenced externally via an inter-
dicator face, e.g. by:
• Bluetooth remote control
• Setpoint specification via analogue input
AI1 or AI2
3.3
• Intervention of building automation via
control input DI1 / DI2 or bus communica-
tion
• Flashes with active twin-head pump con-
nection
Operating Navigate menus and edit content by turn-
3.4
button ing and pressing.
Back button Menu navigation:
• To go back to the previous menu level
(briefly press once).
• To go back to the previous setting (briefly
3.5 press once).
•To go back to the main menu (press once
and hold for > 1 s).
Turns key lock on or off in combination
with the context button > 5 s.
Context but- Opens the context menu with additional
ton options and functions.
3.6
Turns key lock on or off in combination
with the back button > 5 s.
LED display Indicates error code and Bluetooth PIN.
5.1
44
Pos. Name Explanation
LED display Triggers the pump venting function when
5.2 operating
pressed. Turning is not possible.
button
Table 7: Description of operating elements
Settings on pump
Carry out settings by turning and pressing the operating button.
Turn : Menu selection and parameter setting.
Press : Activation of the menus or confirming selected
parameters.
Initial settings menu
The settings menu will appear in the display during initial commis-
sioning of the pump.
ƒ
Stratos MAXO/Stratos MAXO-D: The pump runs in the factory
setting ➜ Application: Radiator; Control mode: Dynamic Adapt
plus.
ƒ
Stratos MAXO-Z: The pump runs in the factory setting ➜ Ap-
plication: Domestic hot water circulation; control mode: Tem-
perature T-const.
