Aquatec® ORCA / ORCA F / ORCA XL
4. Hold the backrest at the center of the head end and carefully
lift it into the end position.
5. Plug the jack socket with the unlocking sleeve C on the spiral
cable B of the hand control A to the jack plug D until the
locking mechanism engages noticeably.
IMPORTANT!
Risk of damage
– Make sure that the backrest doesn't touch the bath
tub edge.
– Place the bath lift further forwards in the bath tub,
if necessary.

3.4 Charging the battery

The bath lift cannot be used when the battery is charging.
WARNING!
Risk of electric shock
– Only recharge the battery in dry rooms at room
temperature (15 °C to 25 °C) and never in the
bathroom.
12
IMPORTANT!
– Only use the charger supplied to charge the battery
in the hand control.
– Only connect the charger to the mains when the hand
control is connected to the charger.
– Make sure that the voltage specifications shown on
the charger correspond to those of the mains supply.
A
F
E
Insert the jack plug F of the charger C into the jack socket E
1.
on the spiral cable D of the hand control A until it engages.
2. Insert the mains plug B of the charger into a power socket.
The red indicator lamp G on the hand control extinguishes
when the battery is completely charged. It is not possible
to „overcharge" the battery.
3. Disconnect the charger from the power socket.
4. Pull the jack plug of the charger out of the jack socket of the
hand control.
B
G
C
D
