DRY CONTACTS IP68 LoRaWAN 863-870 - Guide utilisateur / User guide version V1.0.0

5. WIRING

5.1. Wires description

Zoom on the wires:
FR
EN

5.2. Example of Input Wiring

The following example shows the wiring to be performed to recover the open or closed state of the sensor 1:
Channel 1
Channel 2
Channel 3
Channel 4
GND
GND
Channel 1
Channel 2
Channel 3
Channel 4
GND
GND
Sensor 1
60 of 63
