N N a a m m e e
A Zone 1
B Zone 2
C Zone 3
D Arm
E Disarm
F Alarm
A A r r m m i i n n g g o o r r d d i i s s a a r r m m i i n n g g C C h h a a p p e e r r o o n n e e B B e e d d E E x x i i t t
When armed,C C h h a a p p e e r r o o n n e e Bed Exit monitors the patient's position on the product.
N N o o t t e e - - A notification appears if there is not enough weight on the product to arm bed exit.
To arm bed exit:
1. Tap the desired zone ( Main menu: C C h h a a p p e e r r o o n n e e Bed Exit (page 44)).
2. Tap A A r r m m (D).
After you arm bed exit, the LED light bars on the outside siderails and footboard illuminate green, the bed exit indicator
LED on the footboard control panel illuminates, and the selected zone in the B B e e d d e e x x i i t t screen is highlighted green.
If the patient moves from the armed zone and compromises the bed exit parameter, the LED light bars on the outside
siderails and footboard flash amber, the bed exit indicator LED on the footboard control panel flashes, a sound alarm is
triggered, the compromised zone is highlighted red, and the E E v v e e n n t t M M a a n n a a g g e e r r screen appears (Figure 93).
N N o o t t e e - - If I I n n T T o o u u c c h h is equipped with the i Audio feature option, voice alarms are available. Voice alarms replace the
buzzer alarm and play through the inside siderail speakers.
To disarm bed exit, tap D D i i s s a a r r m m .
2141-409-007 Rev AA.0
A B
D
F F i i g g u u r r e e 3 3 8 8 – – B B e e d d e e x x i i t t m m e e n n u u s s c c r r e e e e n n
F F u u n n c c t t i i o o n n
The patient can move freely, but the alarm sounds when the patient
attempts to leave the product.
The patient can move with limited movement. The alarm sounds when
the patient approaches the siderails or moves toward the foot end.
The patient can move with minimal movement. The alarm sounds when
the patient moves out of the center of gravity.
Arms bed exit
Disarms bed exit
Accesses the alarm settings menu
C
E F
45 EN
