A10-16—Suction Inlet
A10-17—Robot Refill Port
A10-18—Cleaning Tray Module
A10-19—Clean Water Dispensers
Installation
B
Important Information
B1
B1-1—Tidy cords, hard or sharp objects
(such as nails and glass), and loose
items from the ground and move
any unstable, fragile, precious, or
dangerous items to prevent personal
injury or property damage due to
items becoming tangled in, struck by,
or knocked over by the robot.
B1-2—When using the robot in a raised
area (such as in a duplex apartment),
always use a physical security barrier
to prevent accidental falls that may
result in personal injury or property
damage.
Notes:
• When using the robot for the first time, follow it
throughout its whole cleaning route and watch for
potential problems. The robot will be able to clean by
itself in future uses.
• To prevent excessive buildup of dirt on the mop cloths,
floors should be vacuumed at least three times before
the first mopping cycle.
Assembly
B2
B2-1—Align and install the mop axles into
the robot in place until you hear a click.
B2-2—Click
Positioning the Dock
B3
Place the dock on a hard, flat floor (wood/tile/
concrete etc.), flat against a wall, and reserve
a space of at least 0.9 m (2.96 ft) in height,
0.46 m (1.51 ft) in width and 1.2 m (3.94 ft) in
depth. Make sure that the location has good
WiFi coverage for a better experience with
the mobile app. Plug in and make sure that
the status indicator light is on.
B3-1—More than 1.2 m (3.94 ft)
B3-2—More than 0.9 m (2.96 ft)
B3-3—More than 0.46 m (1.51 ft)
Notes:
• If the power cord hangs vertically to the ground, it
may be caught by the robot, causing the dock to be
moved or disconnected.
• The status indicator light is on when the dock is
powered on, and off when the robot is charging.
• The status indicator light turns red if an error occurs.
• Place the dock on a hard, flat floor away from fire,
heat, and water. Avoid narrow spaces or locations
where the robot may be suspended in the air.
• Placing the dock on a soft surface (carpet/mat) may
cause the dock to tilt and cause docking and departing
problems.
• Keep the dock away from direct sunlight or anything
that may block the dock location beacon, otherwise
the robot may fail to return to the dock.
• Do not use the dock without clean water tank, dirty
water tank, dust container cover, disposable dust bag,
or cleaning tray module.
• Maintain the dock according to the Routine
Maintenance. Do not clean the dock power cord and
charging contacts with a wet cloth or tissue.
• All docks are subject to water-based tests before
leaving the factory. It is normal that a small amount of
water remains in the waterway of the dock.
09
Powering On & Charging
B4
Press and hold
to power on the robot.
Wait until the power indicator light is steady,
and then place the robot in front of the dock.
Make sure the dock is plugged in. Then, press
and the robot will automatically return to
the dock for charging. The robot is equipped
with a built-in high-performance lithium-ion
rechargeable battery pack. To maintain battery
performance, keep the robot charged.
B4-1—Dock status indicator light off, robot
power indicator light breathing:
Charging.
Note:
The robot may not be turned on when the battery is
low. In this case, place the robot to the dock for charging.
Connecting to the App
1. Download the App
Search for "Roborock" in the App Store or
Google Play or scan the QR code to download
and install the app.
2. Reset WiFi
Press and hold
and
simultaneously
