until you hear the "Resetting WiFi" voice
message. The reset is complete when the
power indicator light flashes blue slowly.
The robot will then wait for a connection.
Note:
If you cannot connect to the robot due to your
router configuration, a forgotten password, or any other
reason, reset the WiFi and add your robot as a new device.
3. Add Device
Open the Roborock app, tap the "Add
Device" or "+" button and add your device
following the in-app guide.
Notes:
• The actual process may vary due to ongoing app updates.
Follow the guide provided in the app.
• Only 2.4 GHz WiFi is supported.
• If the robot waits more than 5 minutes for a connection,
WiFi will be automatically disabled. If you want to
reconnect, reset the WiFi before proceeding.
Instructions for Use
C
Turning On/Off
Press and hold
to turn on the robot. The
power indicator light will come on, and the
robot will be on standby.
Press and hold
to turn off the robot and
complete the cleaning cycle.
Note:
The robot cannot be turned off when it is being
charged.
Filling the Clean Water Tank
C1
Open the dock cover, lift the clean water
tank, open its lid, and then fill it with tap
water. After filling, close the lid, lock the
latch, and then put the clean water tank
back to the dock.
Notes:
• To prevent damage, do not use any disinfectant and
only use cleaning solution recommended by Roborock.
• Do not add too much cleaning solution to prevent the
robot from working improperly due to slipping.
• To avoid deformation, only use cold water.
• If any water stains remain on the outside of the
water tank, wipe them with a soft, dry cloth before
reinstalling the tank.
Starting Cleaning
Press
to start cleaning. The robot will plan
its cleaning route and in each room, it firstly
draws out edges and then fills the room in a
zigzag pattern. In so doing, the robot cleans all
rooms one by one, thoroughly and efficiently.
Notes:
• To make sure the robot returns to the dock automatically,
start the robot from the dock and do not move the dock
during cleaning.
• Cleaning cannot start if the battery level is too low.
Allow the robot to charge before starting a cleanup.
• Before cleaning, tidy cords (including the power cord
of the dock) and valuables from the floor. Loose
items may be dragged by the robot, resulting in the
disconnection of electrical appliances or damage of
cords and property.
• If cleaning is completed in less than 10 minutes, the
robot will clean the area twice.
• If the battery runs low during a cleaning cycle, the
robot will automatically return to the dock. After
charging, the robot will resume where it left off.
• The robot will retract mop cloth mounts to clean the
carpet. You can also set the carpet as a no-go zone in
the app to avoid it.
• Before starting each cleaning task, make sure that the
mop cloths have been properly installed.
10
Spot Cleaning
Press and hold
to start spot cleaning.
Cleaning range: The robot cleans a 1.5 m (4.9 ft) ×
1.5 m (4.9 ft) square area centered on itself.
Note:
After spot cleaning, the robot will automatically
return to the starting point and be on standby.
Pause
When the robot is running, press any button
to pause it, press
to resume cleaning.
Press
on a paused robot to send it back
to the dock.
Note:
Placing a paused robot on the dock manually will
end the current cleanup.
Sleep
If the robot is paused for over 10 minutes,
it will go to sleep, and the power indicator
light will flash every few seconds. Press any
button to wake the robot up.
Notes:
• The robot will not go to sleep when it is charging.
• The robot will automatically shut down if left sleep for
more than 12 hours.
DND Mode
The default Do Not Disturb (DND) period is
from 22:00 to 08:00. You can use the app to
disable the DND mode or modify the DND
period, or set whether to enable auto top-
up, emptying and drying, to dim indicator
lights, or lower the volume of the voice
message during the DND period.
