GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding
conductor and grounding plug.
The plug must be inserted into an appropriate outlet that is properly installed and grounded in accordance with all local codes
and ordinances.
WARNING
Check with a qualified electrician or service person if you are in doubt as to whether the outlet is properly grounded. Do not
modify the plug provided with the appliance – if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 120-V circuit and has a grounding attachment plug that looks like the plug illustrated
in sketch A in Grounding methods. Make sure that the appliance is connected to an outlet having the same configuration as
the plug.
No adaptor should be used with this appliance.
GROUNDED OUTLET
GROUNDING PIN
AA200
– Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Grounding methods
GROUNDED OUTLET BOX
(A)
ADAPTER
METAL SCREW
TAB FOR GROUNDING
(B)
SCREW
05
(C)
