ends of the main brushes and
bearings.
D1-7—Reinstall the main brush bearings. And
then, reinstall the main brushes and
make sure the color of the main brush,
main brush bearing and the arrow on
the robot match.
D1-8— Reinstall the main brush cover. Make
sure its four teeth are fully seated in
the slots, and press the main brush
cover until you hear it lock with a click.
Notes:
• To securely install the main brush cover, make sure to
press both of the main brush cover latches in place.
• It is recommended to wipe the main brushes with a
wet cloth. If the main brushes are wet, air-dry them
away from direct sunlight.
• Do not use corrosive cleaning fluid or disinfectant to
clean the main brushes.
Side Brush
D2
* Clean monthly and replace every 3-6 months.
D2-1—Turn over the robot, unscrew the
side brush, then remove and clean it.
D2-2—Align the central groove with the raised
position on the robot, then tighten
the screw to reinstall the side brush.
Omnidirectional Wheel
D3
* Clean as required.
D3-1—Use a tool, such as a small screwdriver,
to pry out the axle and take out the wheel.
Note:
The omnidirectional wheel bracket cannot be removed.
D3-2—Rinse the wheel and the axle with
water to remove any hair and dirt.
Air-dry, reinstall, and press the wheel
and axle back in place.
Main Wheels
D4
* Clean as required.
Clean the main wheels with a soft, dry cloth.
Dustbin
D5
* Clean as required.
D5-1—Remove the magnetic top cover of
the robot and press the dustbin latch
to take out the dustbin.
D5-2—Remove the washable filter and
empty the dustbin.
D5-3—Fill the dustbin with clean water and
reinstall the washable filter. Gently
shake the dustbin, and then pour out
the dirty water.
Note:
To prevent blockage, only use clean water without
any cleaning liquid.
D5-4—Allow at least 24 hours for the dustbin
and washable filter to dry thoroughly
before reinstalling them.
Washable Filter
D6
* Clean every 2 weeks and replace every 6-12 months.
D6-1—Remove the filter.
D6-2—Rinse the filter repeatedly and tap it
to remove as much dirt as possible.
12
Note:
Do not touch the surface of the filter with hands,
brushes, or hard objects to avoid potential damage.
D6-3—Allow at least 24 hours for the filter to
dry thoroughly before reinstalling it.
Mop Cloths
D7
* Clean as required and replace every 1-3 months.
D7-1—Remove the mop cloths from mop
cloth mounts. Clean the mop cloths
and air-dry them.
Note:
A dirty mop cloth will affect the mopping
performance. Clean it before use.
D7-2—Stick the mop cloths on the mounts
flat in place.
Robot Sensors
D8
* Clean as required.
Use a soft, dry cloth to wipe and clean all
sensors, including:
D8-1—Reactive Tech Obstacle Avoidance
Sensor
D8-2—Wall Sensor
D8-3—Communication Sensor
D8-4—Cliff Sensors
D8-5—Carpet Sensor
Moving the Dock
D9
To move the dock, grip the handle on the
back with one hand and the inner side of the
front board with the other hand. Do not lift
the dock base directly to prevent the dock
from falling off.
