Dirty Water Tank
D10
* Clean as required.
Open the dirty water tank lid and pour out
the dirty water. Fill the tank with clean water,
close the lid, lock the latch, and shake. Pour
out the dirty water. Lock the lid and reinstall
the tank.
Notes:
• To avoid deformation, only use cold water.
• If any water stains remain on the outside of the
water tank, wipe them with a soft, dry cloth before
reinstalling the tank.
Charging Contacts
D11
* Clean as required.
Use a soft, dry cloth to wipe the charging
contacts on the robot and the dock.
Replacing Disposable Dust Bag
D12
* Replace as required.
D12-1—Open the dock cover and remove
the dust container cover.
D12-2—Remove the disposable dust bag
and discard it.
Notes:
• The dust bag handle seals the bag on removal to
prevent leakage.
• Always install a dust bag before putting back the dust
container cover to avoid auto-emptying without the
bag. You can also disable auto-emptying in the app.
D12-3—Clean the filter with a dry cloth,
insert a new disposable dust bag
into the slot all the way in, and
spread it evenly.
Note:
Make sure the disposable dust bag is properly
installed to avoid waste escaping and damaging the
dock.
D12-4—Reinstall the dust container cover
in place and close the dock cover
to make sure the dust container is
securely sealed.
Cleaning Tray Module
D13
* Clean as required.
D13-1—Remove the cleaning tray module.
D13-2—Remove the cleaning tray and filter
from the module and then rinse
them with water.
D13-3—Reinstall the filter and cleaning tray.
Then, reinstall the cleaning tray
module.
13
Basic Parameters
Robot
Model
RRE0VIC
14.4 V/5200 mAh (TYP)
Battery
lithium-ion battery
Rated Input
20 V 1.5 A
Note:
The serial number is on a sticker on the underside
of the robot.
Empty Wash Fill Dock
Model
EWFD26LRR
Rated Input Voltage 120 V~
Rated Frequency
60 Hz
Rated Input (Dust
6 A
collection)
Rated Input
(Hot-water mop
12 A
washing)
Rated Input
1 A
(Charging & drying)
Rated Output
20 V 1.5 A
