Removing the tool (Fig. 3)
Pull back the locking sleeve (2) and hold it in place and
remove the tool.
Switching ON / OFF (fig. 1)
Switching ON: Press the operating switch (5).
Switching OFF: Release the operating switch (5).
Continuous operation: Press operating switch (5) and
lock with locking switch (4).
Stop continuous operation: Press and release operat-
ing switch (5).
9.
Operation
Danger!
In order to prevent a hazard, the machine may only
be held by the two handles (6/9)!
• Use only proper equipment.
• Make all machine adjustments only with the ma-
chine switched off.
• Never leave the machine unattended while it is run-
ning.
• When switching off, leave the machine only after it
comes to a complete standstill.
• Turn the machine off before you unplug it.
• Always unplug the mains cord. Never pull out the
plug from the wall outlet by holding the cable.
• Perform maintenance and cleaning of the device
regularly.
10. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions. The cus-
tomer's mains connection as well as the extension
cable used must also comply with these regula-
tions.
Faulty power supply cables
Insulation damage often occurs at power supply ca-
bles.
Causes are:
• Pressure points when power supply cables are rout-
ed through the window or door gaps.
• Bends due to improper fastening or guiding of the
power supply cables.
• Interfaces by running over the power supply cables.
• Insulation damage by pulling off the wall outlet.
• Cracks due to ageing of the insulation.
Such defective power supply cables must not be used
and are extremely dangerous to life because of the
insulation damage!
Check power supply cables regularly for damage.
Make sure that the power cable is not connected to
the mains supply when you check.
Electrical connections must comply with the relevant
VDE and DIN regulations. Only use connecting cables
with H 07 RN-F mark.
An imprint of the type designation on the power cable
is mandatory.
AC motor
• The mains voltage must be 230 V ~ / 50Hz
• Extension cables up to 25 m length must have a
cross section of 1.5 mm
Power supply and extension cord must be 3-wire = P
+ N + SL. - (1/N/PE).
The mains supply is secured up to 16 A.
• The product meets the requirements of EN 61000-
3-11 and is subject to special connection conditions.
This means that use of the product at any freely se-
lectable connection point is not allowed.
• Given unfavorable conditions in the power supply
the product can cause the voltage to fluctuate tem-
porarily.
• The product is intended solely for use at connection
points that
a)do not exceed a maximum permitted supply im-
pedance "Z" (Zmax. = 0,357 Ω), or
b) have a continuous current-carrying capacity of
the mains of at least 100 A per phase.
• As the user, you are required to ensure, in consulta-
tion with your electric power company if necessary,
that the connection point at which you wish to oper-
ate the product meets one of the two requirements,
a) or b), named above.
Connections and repairs of electrical equipment may
only be carried out by an electrician.
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Motor data - type plate
