Computer, PC Coupling
SL
Used in PCL read message
Byte
1
2
3
Sequence in message:
Bytes:
Bits:
DISOMAT Opus, Satus, Tersus, Data Communication
© Schenck Process
Explanation
Scale status
Output of DISOMAT
physical input
Output of DISOMAT
virtual (EDP) outputs statusses:
Output of DISOMAT
physical output contact statusses
1
76543210
BV-H2359GB/0902
4.3 Commands Explanations
Bit No.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
2
3
15...8
23...16
Meaning
Underrange
Overrange
Tare computed
Exact zero
Resolved mode
Weight invalid
Tare acquired
No-motion
Contact 1
Contact 2
Contact 3
Contact 4
EDP 1
EDP 2
EDP 3
EDP 4
Contact 1
Contact 2
Contact 3
Contact 4
Contact 5
Contact 6
Standby
Standby
47
