Fig. 24: Celsius

Pak Placement and Thermocouple Connection

Repeat this procedure from slot 9 to 1. Figure contains a diagram of the

final placement of all Celsius

NOTE

For reproducibility, load the S³ Module with the same number of Celsius

fill each Celsius

Pak with the same amount of sample or buffer and place

the thermocouples in the thermowells 1 cm below the surface of the liquid.

All freeze profiles developed at Sartorius Stedim Biotech perform correctly

only with a fully loaded system (10 Celsius

achieved with the freeze profiles provided with the installation software are

directly scalable to 16.6 Liters. Changing the number of Celsius

the scalability of these profiles.

Diagram the position and number of each thermocouple in a lab

notebook or in accordance with company policy.

Close and lock the cover of the S³ Module.

Thermocouple Receptacle Strip

Filled Celsius

Fig. 25: Thermocouple and Celsius

Operating Instructions Celsius

System Operation

Paks and thermocouples.

Paks). For that reason, results

Pak Slot Position

Pak placement in S³ Module.

Benchtop System

Paks,

Paks affects

HTF

Inlet

HTF

Outlet
