4. Place the battery charger onto the screws
using the openings at the back of the battery
charger. The charging control LEDs (green
and red ) have to be located on the lower
[ ]
end of the battery charger.
˜ Operation
˜ Attaching/removing the
battery pack
m CAUTION! RISK OF INJURY!
Always lock the on/off switch
u
accidental starting by moving the rotation
direction switch
5 ] [
(Lock).
NOTE
When you insert a smart battery pack
u
(model no. PAPS 204 A1, PAPS 208 A1)
into the product and press the on/off switch
for the first time, the connection status
LED flashes 3×.
[ ]
Removing the battery pack: Press the
o
battery pack release button
battery pack (Fig. D).
Attaching the battery pack: Align the
o
battery pack to the handle and slide it into it.
Ensure the battery pack clicks noticeably in
place.
The battery pack can only be inserted into the
product in one direction.
˜ Checking the battery pack
charging level
(Fig. B)
Check battery pack charging level: Press the
o
button . The charging level LEDs
[ ]
light up:
42 GB/IE
[
to avoid
6 ] [
into the centre position
. Remove the
[ ]
[
LED
Red/orange/green
]
Red/orange
Red
˜ Charging the battery pack
(Fig. C)
NOTE
The battery pack
u
any time without reducing its life.
Interrupting the charging process does not
u
damage the battery pack.
Charge the battery pack before operation
o
when it is at medium or low charging level.
The charging control LEDs (green
o
red ) indicate the status of the charger
[ ]
and the battery pack:
LED
Red LED lights up
Green LED lights up
Green and red LED
flashing
Red LED flashing
Green LED lights up
(without battery pack)
1. Insert the battery pack into the charger.
2. Connect the mains cord with mains plug
of the charger to the socket-outlet.
3. When the battery pack is fully charged:
Remove the battery pack from the charger.
Then disconnect the mains plug of the charger
]
from the socket-outlet.
Charging level
Maximum
Medium
Low
may be charged at
[ ]
and
[ ]
Status
Battery pack
charges
Battery pack fully
charged
Battery pack
defective
Battery pack too
cold or too warm
Charger ready
[
[ ]
]
