rigid venting (PROPANE ONLY)
40'
30'
V
20'
15'
10'
5'
7'
V
(84")
2'
0'
Base of
air collar
0'
V and H are measured from the center of the vent elbows
This example represents a vent that has a maximum of three 90º elbows, a combined horizontal vent length (H ) of
Since the vent is located in the dark shaded area, it is within the acceptable vent configuration
minimum venting requirements - propane
V = 7 ft
H = 10 ft
H H H H H H H H
5'
10'
10 feet and a combined vertical vent length (V ) of 7 feet.
1-3 elbow zone
1-2 elbow zone
1 elbow zone
20'
15'
H
