minimum venting requirements
3.0 minimum venting requirements
EN
WARNING
!
•
Risk of fi re. Maintain specifi ed air space clearances to vent pipe and appliance.
•
The vent system must be supported every 3'(0.9m) for both vertical and horizontal runs. Use support ring assembly
W010-0067 or equivalent non-combustible strapping to maintain the minimum clearance to combustibles for both
vertical and horizontal runs. Spacers are attached to the inner pipe at predetermined intervals to maintain an even air
gap to the outer pipe. This gap is required for safe operation. A spacer is required at the start, middle, and end of each
elbow to ensure this gap is maintained. These spaces must not be removed.
This appliance uses a 5" (127mm) exhaust / 8" (203.2mm) air intake vent pipe system. Refer to the section
This appliance uses a 5" (127mm) exhaust / 8" (203.2mm) air intake vent pipe system. Refer to the
applicable to your installation.
section applicable to your installation.
For safe and proper operation of the appliance follow the venting instructions exactly. Deviation from the minimum vertical
For safe and proper operation of the appliance follow the venting instructions exactly. Deviation from the
vent length can create diffi culty in burner start-up and/or carboning. Under extreme vent confi gurations, allow several
minimum vertical vent length can create difficulty in burner start-up and/or carboning. Under extreme vent
minutes (5-15) for the fl ame to stabilize after ignition. Although not a requirement, it is recommended for vent lengths that
configurations, allow several minutes (5-15) for the flame to stabilize after ignition. Although not a requirement,
pass through unheated spaces (attics, garages, crawl spaces) be insulated with the insulation wrapped in a protective sleeve
it is recommended for vent lengths that pass through unheated spaces (attics, garages, crawl spaces) be
to minimize condensation. Provide a means for visually checking the vent connection to the appliance after the appliance is
insulated with the insulation wrapped in a protective sleeve to minimize condensation.
installed. Use a fi restop, vent pipe shield or attic insulation shield when penetrating interior walls, fl oor or ceiling.
Provide a means for visually checking the vent connection to the appliance after the appliance is installed. Use a
The vent terminal may be painted with a high temperature paint to match exterior colours. Use an outdoor paint suitable for
firestop, vent pipe shield or attic insulation shield when penetrating interior walls, floor or ceiling.
400°F (200°C). Application and performance of paint is the consumer's responsibility. Spot testing is recommended.
The vent terminal may be painted with high temperature paint to match exterior colours. Use an outdoor paint
note:
suitable for 400°F (200°C). Application and performance of paint is the consumer's responsibility. Spot testing is
If for any reason the vent air intake system is disassembled; reinstall per the instructions provided for the initial
recommended. Appliance should be off.
installation.
This appliance must be installed with a continuous connection of exhaust and air intake vent pipes. Utilizing alternate
note:
constructions, such as a chimney as part of the vent system, is not permitted.
If for any reason the vent air intake system is disassembled; reinstall per the instructions provided for the
Use only Wolf Steel, Metal-Fab, BDM, Simpson Dura-Vent, or Selkirk Direct Temp venting components. Minimum and
initial installation.
maximum vent lengths, for both horizontal and vertical installations, clearances from vent pipes to combustibles and air
This appliance must be installed with a continuous connection of exhaust and air intake vent pipes. Utilizing
terminal locations as set out in this manual apply to all vent systems and must be adhered to. For Metal-Fab, BDM, Simpson
alternate constructions, such as a chimney as part of the vent system, is not permitted.
Dura-Vent, or Selkirk Direct Temp, follow the installation procedure provided with the venting components or on the website
for your venting supplier.
All vent measurements start at the base of the air collar of the appliance.
A starter adaptor must be used with the following vent systems and may be purchased through Wolf Steel or from the
corresponding supplier listed below:
IMPORTANT: For ease of installation, the front frame can be removed. The front
Venting System
frame must be reinstalled prior to installing the nailing tabs.
SureSeal
Direct Vent Pro
Horizontal vent sections: A minimum clearance of 3" (76mm) on the top outside of the enclosure and 2"
(51mm) on the sides and bottom outside of the enclosure all around the vent pipe on all horizontal runs to com-
Pro-Form
bustibles is required. Horizontal vent sections within enclosures require a minimum clearance of 6"(152mm) at the
Direct Temp
top of the vent pipe.
Vertical vent sections: A minimum of 1" (25mm) all around the vent pipe on all vertical runs to combustibles is
Ventis
required except for clearances in appliances enclosures. Vertical vent sections within enclosures require a mini-
mum clearance of 1" (25mm) around the vent pipe.
Connections made by means of an adaptor at the appliance, as well as the connection at the vent terminal must be sealed.
RTV sealant may be used on both the inner exhaust and outer intake vent pipe joints of all other approved vent systems, ex-
cept for the exhaust vent pipe connection to the appliance fl ue collar which must be sealed using the black high temperature
sealant Mill Pac.
For all vent systems is strongly recommend for all installations but required when power venting the appliance, that the outer
air intake joints are sealed using either high temperature silicone (RTV) or a suitable aluminum tape that covers each joint in
the vent system entirely around its circumference. This will ensure the best performance in every application and avoids per-
formance or condensation concerns that may occur in "tightly" constructed homes, particularly those in cold climates.
This template must be used in conjunction with templates 7.2.1 or 7.2.2, depending on
termination shape (i.e. round, or round and square). See appropriate templates folder.
For optimum fl ame appearance and appliance performance, keep the vent length and number of elbows to a minimum.
The air terminal must remain unobstructed at all times. Examine the air terminal at least once a year to verify that
it is unobstructed and undamaged.
14
Rigid and fl exible venting systems must not be combined. Different venting manufacturer components must not
W415-4127 / B-0 / 03.25.24
be combined.
These vent kits allow for either horizontal or vertical venting of the appliance. The maximum allowable horizontal run is 20
Starter Adapter
Manufacturer
Part Number
Metal-Fab
5DNA
Simpson DuraVent
W175-0170
BDM
N/A
Selkirk
5DT-AAN
Olympia Chimney
VDV-NA05-58F
and Venting
Supplier
Wolf Steel
www.mtlfab.com
Wolf Steel
www.duravent.com
BDM
www.dalsinmfg.com
Selkirk
www.selkirkcorp.com
Olympia Chimney
www.olympiachimney.com
and Venting
Website
