Control Box 3S io

AdvANCEd pARAMETER SETTINg

Navigating the parameter list

press ... to...
Access and exit the parameter setting menu
Navigate the parameters and codes list:
. short press = normal scrolling through individual parameters
. press and hold = rapid scrolling through parameters
Confirm:
. the parameter selection
. the parameter value
Increase/decrease the value of a parameter
. short press = normal scrolling through individual parameters
. press and hold = rapid scrolling through parameters

Meaning of different parameters

values
Code description
(bold = default)
p01 Complete cycle 0: sequential
operating mode
1: sequential + timed close
2: semiautomatic
3: automatic
4: automatic
+ cell blocked
5: deadman's control (wire)
p02 Complete operating
0 to 30 ( time delay value
mode automatic timed
closing 2: 20 s
p03 Pedestrian cycle 0: identical to complete cycle
operating mode
operating mode
1: without automatic closing
2: with automatic closing
p04 Short automatic
0 to 30 ( time delay value
closing time delay in
pedestrian cycle 2: 20 s
Copyright © 2015 Somfy SAS. All rights reserved
Setting
completed
= value x 10 s)
= value x 10 s)
Press SET to exit the parameter setting menu.

parameter value display

If the display is fixed, the displayed value is the value selected for
this parameter.
If the display is flashing, the displayed value is the value selectable
for this parameter.
Comments
Each press on the remote control causes the motor to move (initial position: gate closed) as
per the following cycle: open, stop, close, stop, open, etc.
Operation in automatic In sequential mode with automatic timed close:
closing mode is only - the gate closes automatically after the time delay programmed in
authorised if the parameter "p02",
photoelectric cells are - pressing a button on the remote control interrupts the movement
fitted and P07=1 to 4. taking place and the timed close (the gate remains open).
In semiautomatic mode:
- pressing a button on the remote control during opening has no effect,
- pressing a button on the remote control during closing causes it to reopen.
In automatic closure mode:
- the gate closes automatically after the time delay programmed in
parameter "p02",
- pressing a button on the remote control during opening has no
effect,
- pressing a button on the remote control during closing causes it to
Operation in automatic
reopen,
closing mode is only
- pressing a button on the remote control during the closing time
authorised if the
delay restarts the time delay (the gate will close when the new time
photoelectric cells are
delay has elapsed).
fitted and P07=1 to 4.
If there is an obstacle in the cells' detection zone, the gate will not
These operating modes
close. It will close once the obstacle is removed.
are not compatible with
remote control using a
After the gate is opened, movement in front of the cells (safe
TaHoma unit
closure) will close the gate after a short time delay (fixed at 2
seconds).
If there is no movement in front of the cells, the gate will close
automatically after the timed close programmed in parameter "p02".
If there is an obstacle in the cells' detection zone, the gate will not
close. It will close once the obstacle is removed.
In wired deadman mode*
- the gate can only be controlled by continuous action on a wired control,
- the radio controls are inactive.
If value 0 is selected, the gate immediately closes automatically.
Pedestrian cycle operating mode is identical to the complete cycle
operating mode selected.
The pedestrian cycle
If P01=1, the gate does not close automatically following a
operating mode
pedestrian opening command.
parameters can only be
set if P01 = 0 to 2
Operation in automatic closing mode is only authorised if the
The P03 = 2 operating
photoelectric cells are fitted. i.e. P07=1 to 4.
mode is not compatible
Irrespective of the value of P01, the gate does not close
with remote control using
automatically following a pedestrian opening command.
a TaHoma unit.
The automatic closing time delay can be programmed in
parameter "p04" (short time delay) or parameter "p05" (long time
delay).
If value 0 is selected, the gate immediately closes automatically.
