Control Box 3S io

TEChNICAL dATA

gENERAL SpECIfICATIONS
Power supply
Max. power consumption
Programming interface
Climatic operating conditions
Somfy radio frequency
Number of memorisable channels
CONNECTIONS
Programmable safety input
Wired control input
Remote lighting output
Orange light output
24 V controlled power supply output
Safety input test output
Accessories supply output
Offset aerial input
Backup battery input
OpERATION
Forced operating mode
Independent remote lighting control
Timed lighting (after movement)
Automatic closing mode
Orange light warning
Security entry operation
Partial opening control
Gradual starting
Opening speed
Closing speed
Coupling speed when closing
Lock release - electric door-opener
release
Holding gate in open/closed position
Gate leaf shift
Diagnostics
Copyright © 2015 Somfy SAS. All rights reserved
Monodirectional controls (Keygo io,
Situo io, etc.)
Bidirectional controls (Keytis io, Telis
io, Composio io, etc.)
Type
Compatibility
Life
When closing
Before opening (ADMAP)
800 W (with 500 W remote lighting)
7 buttons - 3-character LCD screen
- 20°C/+ 60°C - IP 44
Complete/pedestrian opening control: 30
Lighting control: 4
Auxiliary output control: 4
TX/RX photoelectric cells - Bus cells - Reflex cell - Dry contact output safety edge
Halogen or incandescent only
24 V - 15 W with integrated flashing management
Yes: for possible autotest on TX/RX photoelectric cells
Yes: for possible autotest on reflex cell or safety edge
Yes: compatible with io aerial (Ref. 9013953)
Yes: compatible with battery pack (Ref. 9001001)
24 hours; 3 cycles
Charge time: 48 hours
By pressing the motor control button
Programmable: 0 to 600 s
Yes: programmable reclosing time delay from 0 to 255 min
Programmable: without or with warning (fixed at 2 s)
Programmable : stop - partial reopening - complete reopening
Programmable: no effect or movement refused
Yes: complete opening of motorised gate leaf by M1
Programmable: 10 possible values
Programmable: 10 possible values
Programmable: 5 possible values
Programmable: active - inactive
By current reinjection in case of detection when opening/closing
(only on Control Box 3S Axovia io models)
Saving and consulting data: cycle counter, cycle counter with obstacle detection, number of memorised
radio channels, log of the last 10 stored faults
230 V - 50 Hz
868 - 870 MHz
Unlimited
Dry contact: NC
Dry contact: NO
230 V - 500 W
24 V - 1.2 A max
Yes
Yes
Programmable
22
