Technical Data - geo-FENNEL FLG 6X-GREEN Mode D'emploi

CHARACTERISTICS
· 3 x 360° laser lines -> form 6 laser crosses
· Laser lines switchable separately
· Plumbing function
· Laser plane distance to wall/ceiling min. 12 mm
· Wall/tripod mount
- Magnets on the back
- Strap attachement
- 5/8" tripod connection
· Use with receiver (optional)
· Self-levelling function can be locked for manual use
· 5/8" + 1/4" connection at the instrument bottom

Technical data

Self-levelling range
Accuracy
Laser diode / laser class
Working range w/o receiver
Working range with receiver
Power supply
Operating time
· 1x 360°
· 2 x 360°
· 3 x 360°
Temperature range
Dust / water protection
Weight (instrument with batteries)
*depending on the room illumination
**depending on the direction of the laser
± 3°
± 3 mm / 10 m
green / 2
30 m* (radius)
60 m ** (radius)
Li-Ion
12 h
9 h
7 h
-10°C - +45°C
IP 54
0,76 kg
EN
11
