6. Environment conditions:
- The BENNING CC 1 is intended for making measurements in dry
environment.
- Maximum barometric elevation for making measurements: 2000 m,
- Overvoltage category IEC 60664/ IEC 61010, 300 V category III,
600 V category II,
- Contamination degree II according to EN 61010-1
- Protection class: IP 30 (EN 60529),
- Operating temperature and relative humidity:
For operating temperatures from 0 °C to 30 °C: relative humidity less than 80
%
For operating temperatures from 31 °C to 40 °C: relative humidity less than 75
%
For operating temperature from 41 °C to 50 °C: relative humidity less than 45 %
- Storage temperature: The BENNING CC 1 can be stored at any temperature
in the range from 20 °C to + 60 °C ).
7. Electrical specifications
Note: The measuring precision is specified as the sum of
- a relative fraction of the measured value and
- a current value in A.
The measurement precision applies at a temperature of 23 °C ± 5 °C and a
relative humidity less than 75 %.
7.1 Alternating current measurement
Measurement
range
400 A
Max. equivalent source resistance: 75 Ω
8. Making measurements with the BENNING CC 1
8.1 Preparations for making measurements
Operate and store the BENNING CC 1 only at the specified storage and
operating temperatures. Avoid continuous insulation.
- The nominal voltage and current ratings of the safety measuring cables
included in the scope of delivery correspond to the ratings of the
BENNING CC 1.
- The safety measuring cable is securely connected to the BENNING CC 1
and cannot be removed.
- Check the insulation of the safety measuring cables. Discard the
BENNING CC 1 immediately if the insulation is damaged.1
- Do not clamp the measuring pliers on a live conductor before the
BENNING CC 1 has not been connected to a multimeter.
Strong sources of interference in the vicinity of the BENNING CC 1 can lead
to unstable readings and measuring errors.
- Do not apply any voltage to the output contacts of the BENNING CC 1.

Do not exceed the maximum permitted voltage with respect to
earth potential! Electrical danger!
The highest voltage, that may be applied to the BENNING CC 1 against ground
potential, is 600 V.
8.2 Alternating current measurement
- Set the multimeter to the function "alternating voltage measurement" (V AC)
and select a measurement range that can display voltages from 1 mV to
400 mV.
- Contact the 4 mm safety connector of the spiral type safety measuring cable
with the COM jack of the multimeter.
- Contact the red 4 mm safety connector of the spiral type safety measuring
cable with the voltage input jack (V) of the multimeter.
- Opening lever  Operate and use meas. pliers to  clamp the single wire
live conductor.
- Read off the voltage value on the multimeter and convert to the current
value taking into account the conversion factor.
09/ 2003
Measured
value
3 A
30 A
350 A
400 A
BENNING CC 1
Output Measurement precision
3 mV
30 mV
350 mV
400 mV

± (1,9 % + 0,5 A)
at 50 Hz - 60 Hz
± (3,2 % + 1 A)
at 50 Hz - 60 Hz
