Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
Warning!
Read all the safety information, instructions,
illustrations and technical data provided on
or with this power tool. Failure to adhere to the
following instructions may result in electric shock,
fi re and/or serious injury.
Keep all the safety information and instruc-
tions in a safe place for future use.
Explanation of the warning signs on the
equipment (see Fig. 13)
1 Important! Read the operating instructions.
Follow the warnings and safety instructions.
2 Important! Risk of injury from rotating parts.
Keep your hands, feet and clothing away from
these parts.
3 Always make sure that the machine is stan-
ding solidly whenever you leave it.
4 Important! Hot parts. Keep your distance.
5 Important! Switch off the engine before refue-
ling.
6 Description of the clutch lever: 0 = Tiller blade
stop; 1 = Tiller blade On
2. Layout and items supplied
2.1 Layout
1. Engine / gear unit
2. Reversing starter
3. Spark plug wrench (not illustrated)
4a. Clutch lever
4b. Safety lever
4c. Start/Stop switch
4d. Throttle lever
4e. Choke lever
GB
5. Petrol cock
Assembly set for guard plate / transport
wheel (Fig. 3a - 3e):
6. Transport wheel
7. 1x Screw, M10x80
8. 1x Castle nut, M10
9. 1x Bolt, Ø10x70
10. 2x Split pin, small
11. Guard plate, left
12. Guard plate, right
13. Guard plate for connecting strut
14. 10x Screw, M6×20
15. 10x Locknut, M6
16. 14x Washer, Ø6
Assembly set for cultivator blades / depth
stop (Fig. 4a - 4e):
17. Cultivator blade, inside on the right
18. Cultivator blade, outside on the right
19. Cultivator blade, inside on the left
20. Cultivator blade, outside on the left
21. 2x Limiting disc
22. 7x Bolt, Ø8x40
23. 7x Split pin, small
24. Holder for depth stop / attachments
25. Depth stop
26. 1x Bolt, Ø16 x 111
27. 1x Split pin, large
Assembly set for steering handle / selector
lever (Fig. 5a - 5f):
30. Selector lever
31. 1x Screw, M6×25
32. 1x Locknut, M6
33. Steering handle
34. Handle for height adjustment
35. 1x Screw, M16×160
36. 1x Spring washer, Ø16
37. 1x Washer
38. Cover plate for steering handle
39. 1x bolt M8x35
40. 1x Locknut, M8
41. 2x Screw, M6×35
42. 2x Locknut, M6
43. 2x Cable clip
Assembly set for wheels (Fig. 11a – 11f)
44. 2x Wheel
45. 2x Hub
46. 8x Screw, M10x25
47. 8x Nut, M10
48. 8x Spring washer, Ø10
