Parts subject to wear:
-
The BENNING CM 5-1 is fed by a 9 V block battery (IEC 6 LR 61)
-
The above-mentioned safety measuring leads (tested accessories, 044145)
correspond to CAT III 1000 V/ CAT IV 600 V and are approved for a current
of 10 A.
4.
Description of current clamp multimeter
See figure 1:
The display and operator control elements specified in Fig. 1 are designated
as follows:
1 Polarity marking, for assigning the DC current direction by means of the
polarity indication,
2 Bulge of current clamp, protects against contact with conductor,
3 Opening lever, for opening and closing the current clamp,
4 AutoSense, symbolizes the AUTOTEST function,
5 Zero, null-balance indication for direct current (DC) measurements,
6 APO, Auto Power Off is activated (device will switch off after 20 minutes),
, is indicated if a dangerous voltage is applied > 30 V,
7
8 Polarity indication, any polarity opposed to the polarity markings shall be
designated with „-",
9 Battery status indication, appears when the battery is discharged,
J key (grey), with the following functions:
POWER, for switching the BENNING CM 5-1 on/ off
-
-
(AUTO) POWER OFF, for activating/ deactivating the automatic switch-
off,
ZERO balance, null balance for direct current (DC) measurements,
-
-
(AUTO) HOLD, automatic storage of the measured value,
-
HOLD, storage of the measured value,
K COM jack, common socket for voltage, resistance measurement and con-
tinuity testing,
L Jack (positive
M Range indication,
N LoZi, symbolizes a low input resistance for voltage measurements (4 kΩ ...
375 kΩ),
O Auto, HOLD and AutoHOLD, is displayed if the corresponding storage of
measured values is activated,
 Digital display, for displaying the measured value and range exceedance,
 AUTO BACKLIT, sensor of the automatic background lighting,
 Measuring pliers, for clamping on the single wire current-carrying conduc-
tor,
) This is what the automatic polarity indication for DC voltage refers to,
1
5.

General information

5.1 General details on the current clamp multimeter
5.1.1
The digital display  is a 4-digit liquid crystal display with 14 mm high
numerals, complete with decimal point. The largest numerical value
which can be displayed is 9999.
5.1.2
The polarity indication 8 is automatic. Only one polarity with respect to
the socket/ polarity marking 1 marked "-" is indicated.
5.1.3
The BENNING CM 5-1 can be switched on/ off by means of the key
(grey) J. For switching it off, press and hold the key for approx. 3
seconds.
5.1.4
The overranging is indicated by "0L" or "- 0L" and, in part, an acoustic
warning.
Warning, no indication and prior warning in the event of an overload
condition!
5.1.5
Null balance (ZERO)
Press the key (grey) J for approx. 1 second to carry out a null balance
for direct current (DC) measurements. The null balance is indicated by
a flashing „ZERO" symbol 5 on the digital display.
5.1.6
Storage of measured values „HOLD": The measuring result can be
stored by actuating the key (grey) J. The „HOLD" symbol O simultane-
ously appears on the display. By pressing the key J again, the device
is switched back to the measuring mode.
With the storage of measured values „HOLD" being activated, the
multimeter recognizes a measuring signal deviating from the displayed
value, if the measuring signal of the same unit has increased by 50 dig-
its or if a measuring signal of another measuring function is detected.
The change of measuring signal is indicated by a flashing display or by
a continuous acoustic signal.
5.1.7
Automatic storage of measured values „AutoHOLD" (only for AC/ DC
measurements higher than 3 A): If during switch-on the key (grey) J is
05/ 2019
Appliance front face
), for V, Ω and
1
BENNING CM 5-1
,
12
