– Slide back the aluminium profi le on both legs.
– Place the bevel with one leg on a stop ruler attached to
the circular cross-cut saw.
– To set the dissecting angle (horizontal mitre angle), swivel
the saw unit until the laser beam is congruent with the
line (19.1) on the bevel.
9
Service and maintenance
Always pull the plug out of the socket before
performing any type of work on the machine!
All maintenance and repair work which requires
the motor housing to be opened, must only be
carried out by an authorised service workshop.
To ensure constant air circulation, always keep the coo-
ling-air openings in the motor housing clean and free of
blockages.
The machine is equipped with self-disconnecting special
carbon brushes. If they are worn, power is interrupted
automatically and the machine comes to a standstill.
9.1
Adjusting the laser
If the laser beam does not line up with the cutting edge, you
can adjust both of the lasers. Use an Allen key screwdriver
(size 2.5) to do this. Pierce the points (3.2 to 3.7) marked
on the sticker using the Allen key to reveal the adjusting
screws located underneath.
Adjust the laser as follows:
left/right laser
3.4/3.6:
Rotation on horizontal plane
3.3/3.6:
Rotation on vertical plane
3.2/3.7:
Adjustment parallel to the cutting plane
9.2
Correcting horizontal mitre angles
If the pointer (13.1) no longer rests on the preset mitre
angle values, you can loosen the screw (13.2) and readjust
the pointer.
If the actual (sawn) mitre cut deviates from the preset
value, you can correct this value accordingly:
– Engage the saw unit in the 0° position.
– Loosen the three screws (13.3) that secure the scale to
the saw table.
– Slide the scale together with the saw unit until the ac-
tual value is 0°. You can check this by setting an angle
between the stop ruler and the saw blade.
– Tighten the three screws (13.3) again.
– Check the angle setting by making a test cut.
9.3
Correcting vertical mitre angles
If the pointer (12.3) no longer rests on the preset value,
you can loosen the screw (12.4) and readjust this value.
If the actual value no longer corresponds with the preset
value, you can correct this value accordingly:
– Engage the saw unit in the 0° position.
– Open both screws (12.5).
– Swivel the saw unit until the actual value is 0°. You can
check this by setting an angle between the saw table and
the saw blade.
– Tighten the two screws (12.5) again.
– Check the angle setting by making a test cut.
9.4
Replacing the tabletop insert
Never work with a worn table insert (20.1), replace it with
a new one.
– To replace the table, unscrew the six screws (20.2).
10
Accessories
Use only original Festool accessories and Festool consumab-
le material intended for this machine because these com-
ponents are designed specifi cally for the machine. Using
accessories and consumable material from other suppliers
All manuals and user guides at all-guides.com
19
will most likely affect the quality of your working results
and limit any warranty claims. Machine wear or your own
personal workload may increase depending on the applica-
tion. Protect yourself and your machine, and preserve your
warranty claims by always using original Festool accessories
and Festool consumable material!
Festool offers you a comprehensive range of accessories
for your circular cross-cut saw:
• Saw blades for different materials.
• Trimming attachment (workpiece support surface with
integral measurement scale): allows you to support and
machine long workpieces accurately.
• Cornice stop: support for sloping strip material and cor-
nices.
Other accessories and order numbers for accessories and
tools can be found in the Festool catalogue or on the In-
ternet under www.festool.com.
11
Disposal
Do not throw the power tool in your household waste!
Dispose of the machine, accessories and packaging at an
environmentally-responsible recycling centre! Observe the
valid national regulations.
EU only: European Directive 2002/96/EC stipulate that
used electric power tools must be collected separately and
disposed of at an environmentally responsible recycling
centre.
12
Warranty
For our tools, we give warranty for material and produc-
tion defects in accordance with the locally applicable legal
provisions, but in any case for at least 12 months. Within
the EU member states, the warranty period is 24 months
(verifi cation through invoice or delivery note). Damage
caused by, in particular, natural wear, overloading, in-
correct handling, or damage caused by the operator, or
damage caused through use of the equipment contrary
that specifi ed in the Operating Instructions, or damage
which was known at the time of purchase, is not covered
by the warranty. Furthermore, damage caused by the use
of non-original accessories and consumable materials (e.g.
sanding pads) is also excluded.
Complaints can only be recognised if the tool is returned
while still assembled to the supplier or an authorised Festool
Customer Service workshop. Keep the Operating Instruc-
tions, Safety Instructions, Spare Parts List and purchase
receipt in a safe place. Otherwise the respective, current
warranty conditions of the manufacturer shall apply.
Note
Due to continuous research and development work, we
reserve the right to make changes to the technical content
of this documentation.
13
EU Declaration of Conformity
We solely declare that this product conforms with the fol-
lowing standards and normative documents: EN 61029,
EN 55014, EN 61000 in accordance with the regulations
in Directives 98/37/EC, 89/336/EEC.
Festool GmbH
Wertstr. 20
D-73240 Wendlingen, Germany
Dr. Johannes Steimel
Head of research and development
