Product Overview

1. Handle
2. Self-propel drive bar
3. Blade-control bar
4. Electric-start button
5. Electric-start ignition
6. Rear deflector (not shown) 12. Handle knob (2)
1. Grass bag
Figure 6
7. Washout port (not shown)
8. Battery compartment
9. Cutting-height lever (4)
10. Side-discharge deflector
11. Bag-on-demand lever
Figure 7
2. Side-discharge chute
1. Battery charger (included
with Model 20363 and
20366)
2. Battery pack model 88675
(included with Model
20366)
g284083
g036586
12
Figure 8
3. Battery pack model 88660
(included with Model
20363)
g359246
