Lights do not turn ON at Full Value:
• Make sure that the sensor is not obstructed.
• If Mode is set to A or B, check light level parameter, to find out the amount of light that the sensor is detecting. Cover the sensor
lens to simulate darkness in the room. If the lights come ON, the ambient light level is too high.
• While in Modes A or B, if the red LED blinks 2 times per second when the sensor is triggered, the ambient light level is too high.
• Make sure the FSP-202D is not set to Mode E (Service mode) and time delay rotary trimpot is not at minimum position.
• If lights still do not turn ON, call 800.879.8585 for technical support.
Lights will not go to Dimming Level:
• Check all wire connections and verify the dimming wires are tightly secured.
• Make sure that the sensor is not obstructed.
• Check desired light level setting, to find out the amount of light that the sensor is detecting. Cover the sensor lens to simulate
darkness in the room. If F, the ambient light level is too high.
• The time delay can be set from a minimum of 30 seconds to a maximum of 30 minutes. Ensure that the time delay is set to the
desired delay and that there is no movement within the sensor's view for that time period.
• To quickly test the unit operation, enable test mode and move out of the sensor's view. Lights should fade to the dim level after 5
seconds and then turn OFF after 2.5 seconds.
• If lights still do not turn adjust to the dimming level, call 800.879.8585 for technical support.
Lights will not turn OFF:
• Make sure the FSP-202D is not set to Mode E (Service mode) and time delay rotary trimpot is not at max position.
• To quickly test the unit operation, enable test mode and move out of the sensor's view. Lights should fade to the dim level after 5
seconds and then turn OFF after 2.5 seconds.
• False Triggering may occur if the sensor is exposed to high ambient temperature conditions, so ensure the installed location has
good ambient temperature.
• If lights still do not turn OFF, call 800.879.8585 for technical support.
Catalog #
FSP-202D Selectable Mode Continuous Dimming Low Voltage PIR Fixture Integrated Sensor
FSP-L2 360° lens, up to 44' diameter at 8' height
FSP-L2-S 360° lens, up to 44' diameter at 8' height, with shroud
FSP-L3 360° lens, up to 40' diameter at 20' height
FSP-L3-S 360° lens, up to 40' diameter at 20' height, with shroud
FSP-L7 360° lens, up to 100' diameter at 40' height
FSP-L7-S 360° lens, up to 100' diameter at 40' height, with shroud
FSP-C1 Small collar, for use with FSP-L2 and FSP-L3 lenses
FSP-C2 Large collar, for use with FSP-L7 lens
BZ-50 Power Pack: 120/277VAC, 50/60Hz, 20A ballast or incandescent
BZ-150 Power Pack: 120/277VAC, 50/60Hz, 20A ballast or incandescent, with Hold-On and Hold-Off capability
BZ-200 Power Pack: 120/277VAC, 50/60 Hz, 20A Ballast/ELV/MLV/Incandescent/LED, 16A, E-Ballast/CFL/Plug Load
BZ-250 Power Pack: 120/277VAC, 50/60 Hz, 20A, Ballast/ELV/MLV/Incandescent/LED, 16A E-Ballast/CFL/Plug Load,
with Hold-On/Hold-Off capability
BZ-250-347 Power Pack: 120/347VAC, 50/60 Hz, 16A Ballast/ELV/MLV/Incandescent/LED/ E-Ballast/CFL, 15A Plug Load,
with Hold-On/Hold-Off capability
Sensor colors indicated by one of the following suffixes at the end of the catalog #:
-W = White; -B = Black; -BR = Bronze/Brown; -G = Grey/Silver
TROUBLESHOOTING

ORDERING INFORMATION

Description
