Electrical data
Operating voltage for valves
- via DDL
- via power plug
Cable length for power supply
Current in 0 V line
Internal voltage drop
Output current per valve output
No. of outputs
Number of output bytes
Standards and directives complied with
89/336 EEC
EN 61000-6-2
EN 61000-6-4
Bus coupler
Replacement bus coupler DDL G/Metric CL03/CL03-XL
Replacement bus coupler DDL NPT/UNC CL03/CL03-XL
Termination plug
M12 A-coded male – female 5 poles DDL 'BUS IN / BUS OUT',
IP69K when assembled to CL03/CL03-XL, PVC, stainless steel
AVENTICS | DDL, CL03/CL03-XL | R402003658–BDL–001–AE
24 V DC
24 V DC (10 %/15 %)
Max. 20 m
Max. 4 A
0.6 V
Max. 100 mA
Max. 32
1/2/3/4 bytes (depending on expansion stage)
Electromagnetic compatibility (The EMC Directive)
Electromagnetic compatibility, interference immunity
Electromagnetic compatibility, interference signal
A "Declaration of Incorporation" for the bus coupler can be ordered from
AVENTICS GmbH.

12 Spare parts and accessories

Spare parts and accessories
Part number
R402003532
R402003536
Part number
R402003763
