Installation instructions, for professionals only

6.6. On-time (I/0 and I/0/I)

DIP-Bank 2
Function selection switch 3 – 6
Note: To activate the On-time, additional
settings are required, see 6.1. Operating
mode on page 20 and Fig. 18: Timer I/0
operating mode on page 30 and Fig. 19:
Timer I/0/I operating mode on page 30
Function of the On-time: output begins to run or to clock after switching on the
controller according to the set times.
On-time: Setting the timer (timer function). Switching position of the required
value to ON according to the following table.
x10 – multiplicator (7): The timer set above the value is multiplied by 10.
OFF = deactivated, ON = activated
sec/min – unit (8): Switching from seconds to minutes.
OFF = seconds, ON = minutes
Example: Setting time 3 minutes
Fig. 14: On-time
Fig. 15: Example On-time
p. 26/44
