Installation instructions, for professionals only
WARNING!
Personal injury
● The clamping connections may only be installed by a qualified electri-
cian or similarly qualified person.

5.3. Connecting the light / fan

Clamp the light or fan to the 3-pin light/fan plug according to
Fig. 7: Connection area for 230 V on page 15.

5.4. Connecting the seat sensor (optional)

Clamp the seat sensor line to the 3-pin seat sensor plug according to
Fig. 6: Connection area for sensor/control unit on page 14. Observe
the instructions for this in the operating instruction manual.

5.5. Connecting the foil sensor (optional)

Clamp the foil sensor line on the 2-pin foil sensor plug to FF accord-
ing to Fig. 6: Connection area for sensor/control unit on page 14.

5.6. Connecting the HV input (remote start/enable input)

The input becomes active by applying alternating current
(230 V / 50 Hz) – depending on the remote start or enable input
setting. The input is connected using 2-pole HV plug according to
Fig. 7: Connection area for 230 V on page 15.
The EN 60335-2-53 states that the controller (in the remote start
setting) must be set to "Standby for remote operation" mode before
each remote start procedure.
Refer to chapter 6.9. HV input (remote start/enable input) on page
32 to follow the exact step-by-step procedure.
p. 16/44
