Installation instructions, for professionals only
5.7. Connecting the safety temperature limiter
(optional)
When using infrared heaters and infrared plates without intrinsic safety,
a safety temperature limiter is required and must be connected!
The STB line is connected as shown in Fig. 6: Connection area for
sensor/control unit on page 14 to the STB connection.

5.8. Connecting the infrared heater / infrared plate

Connect the infrared heater/infrared plate to the connection provided
according to Fig. 7: Connection area for 230 V on page 15. Observe
the instructions for this in the operating instruction manual.
p. 17/44
EN
