16.3.1 - Objets du NSM

Le NSM comporte un objet "Device" et 16 objets BACnet prédéfinis.
Pour le NSM, le nom de l'objet "Device" est le nom spécifié lors de l'étape 4 (voir section 6.2.4 - Renseignement sur le
site d'exploitation), et à défaut "NSM".
Nom Type
NSMControlEnable BV
SystemMode AV
ProductionMode AV
CoolingCaller AV
HeatingCaller AV
CoolThreshold AV
HeatThreshold AV
DigitalIntput1 BV
DigitalIntput2 BV
DigitalIntput3 BV
DigitalOutput1 BV
DigitalOutput2 BV
DigitalOutput3 BV
AlarmSystem BV
UnitSystem BV
Notification NC
NOTE: La modification du système d'unité doit être effectuée à partir de l'interface tactile du NSM.
16.3.2 - Objets de chaque unité terminale
Chaque unité terminale comporte un objet "Device" et 21 objets prédéfinis.
Pour l'unité terminale, le nom de l'objet "Device" est le nom par défaut (UNIT001 à UNIT128)
Nom Type
Occstat BV
oprmode AV
CTRLTEMP AV
Ctrlpnt AV
InAir AV
InCo2 AV
Distatus AV
OUTCWV AV
OUTHWV AV
OUTFAN AV
OUTEH AV
OUTAIR0 AV
ovrmode AV
Tcstatf AV
alrmstat AV
Mstraddr AV
Occset AV
Occdb AV
Ecodb AV
CommFail BV
Notification NC
NOTES:
Les objets distatus, ovrmode, alrmstat sont fabriqués respectivement à partir des points CCN:
• DISCIN1 et DISCIN2,
LSHDFLG et OFFMODE et FRSTPROT
•
• almstat1 et almstat2
76
Instance Options Accès
1 RW
1 COV R
2 COV R
3 COV R
4 COV R
5 COV RW
6 COV RW
2 R
3 R
4 R
5 R
6 R
7 R
8 R
9 R
1 RW
Instance Options Accès
1 RW
1 COV R
2 COV, IR R
3 COV R
4 COV R
5 COV, IR R
6 COV R
7 COV R
8 COV R
9 COV R
10 COV, CMD R
11 COV R
12 COV, CMD R
13 COV R
14 COV, IR R
15 COV RW
16 COV RW
17 COV RW
18 COV RW
2 IR R
1 RW
Description
NSM Control Enable
System Mode: 0= No mode, 1= None, 2= Cool, 3= Heat, 4= Both,
5= Cool To Heat, 6= Heat To Cool
Production Mode: 0= None, 1= Delay, 2= Cool, 3= Heat, 4= Both
Number of Cooling Caller: 0-100%
Number of Heating Caller: 0-100%
Cool Threshold: 0-100%
Heat Threshold: 0-100%
Digital Intput#1: 0= Open, 1= Closed
Digital Intput#2: 0= Open, 1= Closed
Digital Intput#3: 0= Open, 1= Closed
Digital Output#1: 0= Open, 1= Closed
Digital Output#2: 0= Open, 1= Closed
Digital Output#3: 0= Open, 1= Closed
Alarm System: 0= Normal, 1= Alarm
Unit system: 1= Metric, 0= Imperial
Notification Class for NSM Device
Description
Occupancy: 0= Unoccupied, 1= Occupied
Operating Mode: 0= Satisfied, 1= Cooling Demand, 3= Heating
Demand
Control Temperature
Control Point
Air Damper Input: 0-100%
CO Input: 0-100%
2
DI Status: 0: DI1 & DI2 Open1: DI1 Closed, 2: DI2 Closed,
3: DI1 & DI2 Closed
Cooling Water Valve Output: 0-100%
Heating Water Valve Output: 0-100%
Fan Output: 0-100% or 0= Stopped, 1= Low, 2= Medium, 3= High
speed
Heater Output: 0= Off, 1= On
Air Damper Output: 0-100%
Override Mode: bit2: Loadshed/bit1: OFFMode/bit0: Frost Protection
1= Enable 0=Disable
NTC Status
Alarm Status : AlmStat1 * 65536 + AlmStat2
Master Slave : 0-192
Setpoint
Occupied Deadband
Unoccupied Deadband
Communication failure: 0= Normal, 1= Alarm
Notification Class for NTC Device
