Seizure of the registers
The LS100 has 8 CVs which are used as follows:
CV
1
3
4
5
6
7 Version number (please read out)
8
The value stored in CV1 determines the address or "numerical value" with which
the connected switching devices are addressed.
CV3 to 6 behave similarly: The values stored here determine the features of the
outputs. Table 2 contains the values to be entered for a desired output feature.
Value
0 - 15
33 - 47
Values other than the ones stated here are not permissible and will lead to
different results.
occupied with
Address
Features output 1
Features output 2
Features output 3
Features output 4
Manufacturer ID
Table 1: Seizure of the registers
Pulse output, variable pulse duration
32
Flashing, variable frequency
Table 2: Output features
permissible value range
0 - 15; 32; 33 – 47
0 - 15; 32; 33 – 47
0 - 15; 32; 33 – 47
0 - 15; 32; 33 – 47
Feature
Continuous output
33
1 – 256
-
99
E
